Mental Models of Slate

Configurable Joins: The Basics of Joins

Published on October 20, 2025

This is the first in a new series of articles on helpful mental models for learning Slate. This series is designed for users who are new to Slate or taking on a new role, and who want to better understand what's happening behind the scenes. With the right mental models, you'll become a more effective troubleshooter, develop good instincts for how the tools work, and make better informed decisions when building in Slate.

If you're new to queries in Slate and wondering about the idea of related data, when to join, why you need to join, which join to choose, or why you're not seeing the results you expect, this article is for you. When I lead trainings on Configurable Joins, I find there are certain examples that help make CJs "click" for people, especially if they can interact directly with some sample records. The interactive explainers below will introduce you to the first of those examples, about the basics of joins and related data.

Viewing Related Data on Record Tabs

When you're working with individual records in Slate, you're able to toggle between their tabs and subtabs to see detailed information about their applications, addresses, schools, and more.

Here's a simplified interface looking at the person records for four students. You can toggle to a different person and click on their subtabs to see their related data:

Some students have one related school record, while others (like Liam) have multiple.

Picturing Related Data as Lists

One of the basic mental models for querying in Slate is to start picturing related data as lists.

We could make a list for each person (Olivia's schools, Liam's schools). Or, we could make a single list of everyone's schools.

Here's what it would look like to arrange the related data from our subtabs as lists for each student, and then as consolidated lists for all four people:

These lists are our query bases, the starting point for any query. When building a new query, we tell Slate which list we want to use as the base of the query.

Bringing in Related Data Using Joins

If we choose a Person query base, by default we already have all person data available to use as exports or filters, but we won't have any related data from the other subtabs until we add a join.

Let's see what that looks like at the individual record level, for both Olivia and Liam:

By joining to the schools table or the address table, we make those fields available for use in our query.

But, in the example above, Liam has two schools. Our 'Join' button doesn't make all of his schools available, only one specific school. Each join only brings in one row from the related list.

If we want to bring in more than one school, we need to add more than one join, and we need to tell Slate which school to bring in for each join.

Why Joins Use Rank

Out of the box, Slate provides standard joins to bring in each of the related rows based on rank.

Rank is Slate's way of putting someone's list of schools or addresses in sort order, where the rank 1 school is the top school, the rank 2 is the next school and so on (if you're ever curious, there's a detailed explanation for how Slate ranks each table in the Knowledge Base article on Determination of Table Ranks).

Now, if we look at Liam, we can pick either his Rank 1 or his Rank 2 school and make those available to the query:

But the actual query interface in Slate includes more options. Which option do we actually want?

Custom Joins vs. Standard Rank Joins

The query tool lets us join using the default rank or a custom rank, when we don't want to use Slate's default sort order.

• Rank: Options like School by Rank Overall or School by Level of Study, Rank
• Custom: Options like Schools

In each case, the join needs to be configured to tell Slate which row we want.

Here's the final version of the simplified interface that's closer to how the query tool actually presents join options. You can click 'Add Join' and choose whether you want the default rank join (and enter which rank number you want) or a custom rank (where you tell Slate how you want to sort instead).

Of course, in the query tool, we're working with a list of records. We don't join to Olivia's rank 1 school and separately to Liam's rank 1 school: we add our joins to the query overall, which tells Slate "For each record in our results, bring in data from the rank 1 school, if it exists." To reflect this, the simplified interface now shows joins persisting if you toggle between records. If a record doesn't have a row with that rank, the join will be grayed out.

We can add and remove as many joins as we want, including (if we're not careful) adding joins that bring in the same data multiple times. This is one of the most common errors new users make when building queries: they'll add a join from Person to Schools, then, under 'Extended Exports', search for a field like Level of Study and accidentally add a new join, even though they already had access to the data.

Takeaways

When you're building queries, it can be helpful to start by picturing the tabs and subtabs on a record that you want to include, then imagine what those tabs would look like if they were lists. How do you want to interact with those lists, and which list do you want to use as the base of your query?

In a query, you're telling Slate what you want it to do for each record: if someone has multiple schools or addresses, which one should be brought in so you can use it for exports and filters?

Each join only brings in one row. If you want to include columns for both rank 1 school name and rank 2 school name, you need to add separate joins, and you need to configure those joins by adding the rank number or a custom sort order (tip: you almost always want to use the default rank joins, not custom).

When you're adding a new field, you can check whether it's already available by looking at 'Direct Exports', which is similar to the 'Available Data' window in our examples above. Adding a join makes new fields available in that 'Direct Exports' section. You should only pick from 'Extended Exports' if a field is not yet available.

With these basics in mind, you'll be able to join successfully to related data, pulling in precisely the rows you need.

Ready to explore the concept of subquery exports? Check out the article on The Basics of Subquery Exports.

If you're finding this series on Mental Models of Slate useful but you're looking for additional training or live working sessions over Zoom on Configurable Joins, reach out to info@predicatehighered.com to discuss whether we might be a good fit.
